Open source GitOps integration platform

Weik.io manages your integrations, APIs, file transfers and events

Integrations in Weik.io are Apache Camel routes in YAML, XML or Java, and they can use Camel's components and kamelets. You keep them in Git and promote each version from devtest to production with the weikio CLI or the admin UI. Every integration has its own logs, metrics and traces. Weik.io is open source under the Apache License 2.0 and runs on your own servers, in your cloud or in Weik.io Cloud.

/integrations/finance/erp-invoice-export
The page of finance/erp-invoice-export with version 1.2.0 running in devtest on the agent dev and in production on fi-01, where 1.1.0 ran before, the last hour of production with no failed messages, and its log linesThe page of finance/erp-invoice-export with version 1.2.0 in devtest and 1.1.0 in production, where 8 of 88 messages failed in 15 minutes, and the last hour of production with its messages, failures, memory and the counter invoices_processed

Some of the companies that run their integrations on Weik.ioFirst production installation in January 2018

For developers and for enterprises

For developers

Try it on your machine

Run the whole platform on your machine in the Try Weik.io dev container, or call the live demo's API from your terminal and find your own call in its admin UI. weikio init hello creates an integration, and weikio run hello builds it, deploys it to devtest and follows its log.

Terminal
$ weikio init hello
$ weikio run hello

For enterprises

Customers, controls and support

Cross Wrap, Dinolift, Jouka, Junttan, Oscar Software, Steerprop and Tana run their integrations on Weik.io, and the first installation went into production in January 2018. Weik.io runs on as many servers as you need across your data centres with failover, and backs up on a schedule to your own storage. People sign in through Microsoft Entra ID or any OpenID Connect provider, and the audit log keeps every change for 400 days. Weik.io is made in Finland by Adafy Oy, and Weik.io Cloud runs in Helsinki.

What Weik.io manages

Camel integrations

Apache Camel integrations in YAML, XML or Java, each with versions, environments, logs, metrics and traces.

routes/fetch-invoices.camel.yaml
- route:
    from:
      uri: timer:tick?period=60000
      steps:
        - setHeader:
            name: Authorization
            simple: "Bearer {{erp-api-key}}"
        - to: "{{erp-url}}/api/invoices/pending"
        - to: direct:transform

Managed file transfer

Files between SFTP and FTP servers, cloud storage and local folders on a schedule, with a record of every file.

finance/transfers/supplier-invoices.yaml
kind: mft
spec:
  schedule: "0 0 5 * * ?"
  operation: move
  source:
    remote: supplier-ftp
    path: /outgoing
  destination:
    remote: invoice-archive
    path: invoices/incoming

API management

A gateway in front of any HTTP API, with keys, rate limits and a record of every call.

finance/apis/invoices/v1.yaml
kind: api-version
spec:
  type: proxy
  rateLimit:
    permitLimit: 600
    window: 1m
  clusters:
    - ClusterId: erp
      Destinations:
        erp: { Address: "{{erp-url}}" }

The admin UI

/
The Home page with devtest and production, and the production list with erp-invoice-export, invoice-archiver, the invoices API and supplier-invoices, with the version of each and whether devtest runs the same oneThe Home page with devtest and production, and the production list with erp-invoice-export, invoice-archiver, the invoices API and supplier-invoices, with the version of each and whether devtest runs the same oneThe Home page with the environments test, devtest and production and the deployments running in eachThe Home page with the environments test, devtest and production and the deployments running in each
Home shows each environment with its deployments and lists what runs in production, with the version of each integration, transfer and API and whether devtest runs the same one.

From Git to production

A change starts in a folder in Git. A pull request runs weikio diff, and the pipeline posts the plan as a comment. The merge runs weikio apply and the change reaches devtest. Promoting a tested version to production is a pull request that changes the version, and production applies it after the repository's required reviewers approve. git revert rolls a change back through the same steps.

Integrations, APIs, channels and deployments are YAML documents you can keep in your repository. A pull request runs weikio diff and posts the plan, and the merge applies the change to devtest. Promotion to production is a pull request that changes the version. A change made in the admin UI becomes a version too, and the audit log records who made it.

GitOps and the CLI

Terminal
$ weikio apply -f ./finance/erp-invoice-export --bump minor
Target: https://hub.example, project finance (from finance/project.yaml)
Uploading 2/9 files, building...
integration finance/erp-invoice-export updated (version 1.1.0, built in 17.3 s)
integration.yaml updated to 1.1.0

$ weikio promote finance/erp-invoice-export --from devtest --to production
Target: https://hub.example, project finance (argument), environment production (--to)
This will promote 'finance/erp-invoice-export' 1.1.0 to production environment 'production'.
Continue? [y/N] y
Promoting finance/erp-invoice-export 1.1.0 (latest) to production...
deployment production/finance/erp-invoice-export updated (version 1.0.0 -> 1.1.0, previous 1.0.0)
Agents: 1 of 1 running after 4.0 s

$ weikio rollback finance/erp-invoice-export --env production
Target: https://hub.example, project finance (argument), environment production (--env)
deployment production/finance/erp-invoice-export updated (version 1.1.0 -> 1.0.0, previous 1.1.0)
Agents: 1 of 1 running after 3.7 s

Where it runs

The hub runs a message server, the backend, the gateway and the log, metric and trace stores on one server, or on as many as you need for high availability, and it publishes port 443. Agents in three places connect to it: at a factory inside a customer network, in the customer's Azure account and as cloud agents in Weik.io Cloud. Each agent starts one Java process per running integration, with a small message server beside the agent, and it opens two outbound connections to the hub on port 443, wss for the message server and https for telemetry. No agent accepts an inbound connection.

A Weik.io installation: the hub at the top, and the agents, which connect out to it on port 443. The leaf node beside each agent is a small message server that carries its messages.

Integrations run wherever you install an agent: on your on-premise servers, in your cloud account, inside a factory network or on cloud agents in Weik.io Cloud. An agent connects to Weik.io with two outbound connections on port 443 and opens no inbound port.

Weik.io runs on one server, or on as many as you need for high availability, in one data centre or across several. The CLI runs on Linux and Windows, and agents run on Linux hosts and on Windows Server 2022 and 2025.

How Weik.io is put together

Open source and open standards

Weik.io is open source under the Apache License 2.0, and it uses open standards where your integrations meet other systems:

  • Apache Camel for integrations
  • CloudEvents 1.0 for stored and delivered events
  • OpenAPI for the platform's HTTP API and for calling other APIs from integrations
  • OpenTelemetry for logs, metrics and traces
  • OpenID Connect for sign-in and API subscriptions

Open source and open standards

Ways to run Weik.io

Self-hosted

Free

Every feature, on your servers or in your cloud, with support from the Weik.io team by agreement.

Weik.io Dedicated

From €2,990 a month

Run by the Weik.io team in your cloud account or data centre.

Weik.io Cloud

From €590 a month

Managed Weik.io on servers in Helsinki, operated by Adafy Oy.

Compare the prices

Try Weik.io

Run Weik.io on your laptop, or book a demo and an engineer from the Weik.io team shows it with integrations like yours.

Sign in to the live demo

Sign in with the shared viewer account, which can open every screen of the example projects and can't change anything.

E-mail
viewer@demo.weik.io
Password
try-weikio-live-demo
Open the live demo
